Minibo 5M

Overview

Montarbo MiniBO. Big Sound. Small format. MiniBO-5M is a versatile and portable 2-way active loudspeaker designed primarily for installation and professional audio applications, while remaining flexible for multimedia and small PA use. Equipped with a built-in 2-channel mixer and Bluetooth® stereo connectivity, it easily adapts to a variety of scenarios: from background music systems to compact portable setups. A dedicated DSP with four selectable presets optimizes performance according to placement and usage, ensuring clear and balanced sound in any environment. Despite its compact size and lightweight polypropylene enclosure, the delivers impressive output thanks to a 5.25" woofer and 1" compression driver powered by a 60W RMS Class-D amplifier (120W peak). Installation is quick and flexible: the enclosure features two integrated M10 fly points for fixed mounting and is compatible with optional Wall Bracket and Tilt Bracket accessories for wall or ceiling installation.

Features

• 5,25'' Woofer

• 1'' compression driver horn loaded

• Full Range PSU

• TWS 5.4 Bluetooth

• 2 channels preamplifier

• Mic/Line selection

• Combo + XLR (mix out)

• 2x M10 screw

• Brackets available

• PP enclosure

Application

MiniBO is ideal for delivering clear, balanced sound in compact portable and installed audio systems. Its controlled frequency response and integrated amplification make it perfectly suited for background music, speech, presentations, and multimedia playback in small-to-medium environments.

Specification sheet

Acoustical Data

Speaker Type

2-way active loudspeaker

Frequency Response [-10 dB]

76 Hz - 20 kHz

Max SPL

120 dB

HF

1" exit (V.C.: 1")

LF

5.25" (V.C.: 1.5")

Dispersion

70° H x 50° V

Crossover Frequency

2700 Hz

Amplifier

Amp Class

TBA

RMS Power

60 W

Peak Power

120 W

DSP

Advanced Functions

FIR filters 28/56 Bit

AD/DA Converter

24Bit / 48kHz

Controls

Preset button CH1-CH2-MAIN level CH1 LINE/MIC switch

Connectors

Dimensions

W x H x D 170 x 304 x 190 mm [6.69" x 11.97" x 7.48"]

Weight

4.4 kg [9.70 lb]

Cabinet

Polypropilene
